Enhanced Reinforcement Range

FILON SUPASAFE TRIPLE REINFORCED PROFILED GRP ROOFLIGHTS

FILON Supasafe rooflights are triple reinforced and made with polyester resins and glass fibre mats, featuring two additional reinforcement layers, Including a stitch woven reinforcing glass matt. They have undergone an ACR(M)001 Test for Non-Fragility of Large Element Roofing Assemblies, and achieved a Class B non-fragility rating. They offer impact resistance and load-bearing capabilities comparable to 0.7mm steel sheet.
Contact us today to find out more.

FILON DR Rooflights

FILON DR (double reinforced) profiled GRP rooflights are made with polyester resins, glass fibre mat, and an extra reinforcing woven glass layer compared to traditional GRP rooflights.

They are assessed according to ACR(M)001 Test for Non-Fragility of Large Element Roofing Assemblies and have a Class B rating when used as a single skin application or part of a multi-layer assembly like FAIRs and site-assembled insulating rooflights.

The DR range comprises of CEDR24 (2.44kg/m²) with better strength characteristics than standard CE30 (3.06kg/m²), and CEDR30 (3.06kg/m²) which slightly surpasses standard CE36 (3.66kg/m²).

Benefits of Filon’s Enhanced Reinforcement Range

For applications where increased strength, load bearing, span and resistance to mechanical damage is required, FILON’s DR (double reinforced) profiled GRP rooflights with enhanced reinforcement are an ideal solution.

Excellent resistance to weathering image

Excellent resistance to weathering

Our Supasafe Triple Reinforced and DR Double Reinforced Profiled GRP Rooflights come with Filon Protect to the weather face, a highly durable and weather-resistant protective film that increases sheet lifespan and reduces yellowing.

Accurate profile matching to steel sheet image

Accurate profile matching to steel sheet

FILON Supasafe and DR rooflights are made using advanced glass reinforcement technologies and a precise manufacturing process, resulting in a lighter and thinner sheet with comparable impact resistance and load-bearing capabilities to heavier standard production sheets. This thinner sheet allows for more accurate profile definition, enabling better sealing between side and end laps in rooflights and roof sheets.

View technical documents

Fire resistance image

Fire resistance

FILON rooflights undergo testing in accordance with BS 476 parts 3, 6, and 7, BS EN 13501 Part 5, and BS 2782-0 Annex B Method 508A and are available in three fire retardant grades: Filon Grade 300, Filon Grade 104 and Filon Grade 101. All achieve BROOF (t4) to BS EN 13501 Part 5. For guidance on which fire grade is suitable for specific applications, please contact FILON’s Technical Department or refer to our Technical Documents page.

Accurate profile matching to steel sheet

Wide range of profile options image

Wide range of profile options

FILON reinforced rooflights are available in a wide range of commonly used roofing profiles. Special colour tinted rooflights can be supplied to special order.

Light transmission image

Light transmission

FILON DR and Supasafe rooflights provide excellent levels of light transmission similar to that of standard translucent GRP rooflights.


WHY CHOOSE FILON AS YOUR PREFERRED SUPPLIER?

Our experience and industry-leading product offering are there to help you build structures with outstanding physical, environmental and safety properties. As a company we boast:

  • More than 60 years’ experience
  • ISO 9001 and accreditation
  • Global supply

Find out more about our business and the products we have available, or contact our team today.
